Electrical installations of the future
For electrical installations, our pre-terminated flat cable systems offer efficiency, convenience and safety, with tested connections that virtually eliminate faults. Ideal for large projects and e‑mobility installations.
Pre-assembly is the future of electrical installations
Pre-assembly is the future of electrical installations
The advantages
- Efficient
Installation is reduced to an absolute minimum. - Convenient
Simply plug in on-site. - Pre-tested
We test contact points multiple times. - Safe
Failures are practically impossible.
Efficiency and safety
Woertz delivers complete flat-wire strands with pre-assembled, labelled and checked feed and junction boxes to construction sites; these then only need to be mounted and plugged in on-site. Major mental work on-site is no longer required, and the possibility of failure is significantly reduced.
Particularly for large projects with repeating rooms and lots of storeys, electrical installation is massively sped up and costs significantly reduced.
Simple planning – classic or digital with BIM
The wire-assembly list for pre-assembly can be exported directly from BIM software with the Woertz BIM data from the online catalogue or entered into a table.
Pre-assembly with flat wires vs. pluggable electrical installation
Pre-assembled flat wires are more energy-efficient, safer, quicker and more cost-effective than pluggable electrical installation.
With pluggable electrical installation, the live main line is interrupted and power is conducted via multiple contact points in a plug connection (wire plug, socket, socket wire). This results in a significant loss of voltage and power. Contact points are always weak points. Serial contact points in particular can result in a large-scale outage. Plus, connecting wires are often only available in standard lengths, leading to unnecessarily long wires.
With flat wires, the live main line is not interrupted. The ideal power supply is always guaranteed. Failures at one contact point only affect that contact point, and not the entire system. Junctions can be anywhere on the wire. There is no unnecessary length. Additional junctions can be added at any time. Pre-assembled flat wires are also quicker to install and easier to plan than pluggable electrical installations with lots of wires and plugs.
By loading the video, you agree to YouTube’s privacy policy.
Learn more
Practical example of pre-assembly
Pre-assembled flat cable installation
Pre-assembled flat-wire strands for DALI, KNX or Power are delivered to the construction site on time, already pre-tested and labelled.
They only need to be attached and plugged into their consumers.
Pre-assembled junction boxes with a pre-mounted output wire to charging stations save up to 300% of installation time. Junction boxes can also be pre-assembled on the flat wire. The wire only needs to be fixed to the wall with the clamps, and the pre-stripped output wire connected with the charging stations.
